Paraméterek
TECHNICAL SPECIFICATION:
- PUMP CAPACITY: 11 LT/HMAX.
- ASPIRATION: 2 MT VERTICAL - MAX. FLOW RATE: 8 MT.
- BETWEEN FLOAT HOUSING AND PUMP
- SUPPLY VOLTAGE: 230 V
- ALARM CONTACT: NO-NC 8A
- TUBE DIMENSIONS: 4x6 (mm) PUMP
- DIMENSIONS: L62-D30-H55
- FLOAT HOUSING DIMENSIONS: L 87 - P 34 - H 38 (mm)
- PROTECTION RATING: IP20
- BOX COMPLETE WITH MOUNTING PLATE, FLOAT, PUMP, 1M-LONG TUBE, BREATHER TUBE, 2-SIDED ADHESIVE PADS, ADAPTER SLEEVE AND REMOVABLE ELECTRIC CONNECTOR
- BIGGER RESERVOIR (87 L - 34 H - 38 D mm) EQUIPPED WITH BUILT-IN ANTI-ALGA SANITIZING TABLET TO OPTIMIZE PUMP OPERATION.
WALL MOUNTING APPLICATIONS:
- WALL-MOUNTED SPLIT UNITS
- CONSOLES
- FAN COIL UNITS
CEILING MOUNTING APPLICATIONS:
- CEILING-MOUNTED A/C UNITS
- DUCTED SYSTEMSI
